Codes
and Facilities
Codes with copyrights
(7)
Ø MultiPhyChem
V1.0
MPC
is to simulate multiphysiochemical coupling transports in porous media
Ø Imbidisplacement
V1.0
IMD
is to simulate the imbibition and displacement in tight and low-permeable
reservoir
Ø Quartet
Structure Generation Set (QSGS)
QSGS is for
reconstruction of porous media microstructure with statistical and stochastic
features (rocks, soil, and composites for examples)
Ø PBDOM
PBDOM is for
directly solving phonon Boltzmann equation for heat transport in nanomaterials.
Ø Generalized
Enskog Monte Carlo (GEMC)
GEMC
is for high-Kn real gas flows modeling in MEMS/NEMS and astronautics (re-entry
problem for example)
Patents (US patents, 2;
China patents, 21)
¨¹ Reservoir
Chip and Method for Producing the Same (US Patent: US-2021-0001332-A1)
¨¹ Fixing
lamp for microfluidic chip (US Patent: US-2021-0060570-A1)
¨¹ One
chucking appliance for microfluidic chips (China Patent)
¨¹ One
design and fabrication method for reservoir chip (China Patent)
¨¹ One
digital regeneration method for hierarchical microstructure of rocks (China
Patent)
¨¹ One
fast measure method for permeability of tight rocks (China Patent)
¨¹ One
measurement method for microscale modulus of gel particles (China Patent)
Designed Facilities
(with copyright)
n Permeability meter for ultra-tight materials
n Reservoir on microfluidic chip platform
Facilities (LMIT)
HAAKE
Mars III rheometer system
¨¹ integrated
electronics for temperature modules and valves
¨¹ torque
range from 3nNm up to 0.2Nm
¨¹ Nf -50
up to 50 N (0.001 N)
¨¹ CS
10^{-7} up to 1500 rpm
SurPASS
Zeta potential analyzer (Anton Paar)
¨¹ Steaming
potential: -2000~+2000 mV
¨¹ Steaming
current: -200~200 ¦ÌA
¨¹ pH:
2~12
¨¹ Temperature:
20~30¡ãC
¨¹ size:
540 mm¡Á430 mm¡Á593mm
DL700E+
thermal infrared imager with high temperature module (1200 ¡ãC)
TCI
thermal property analyzer
¨¹ Thermal
conductivity: 0.04~120 w/(m K)
¨¹ time:
0.8~5 second
¨¹ minimum
sample size: 17 mm
¨¹ temperature:
-50~200 ¡ãC
¨¹ Accuracy:
better than 1%
Drop
volume tensiometer (KRUSS)
¨¹ Measurement
range:0,1 - 100 mN/m
Contact
Angle Measurement (KRUSS)
¨¹ contact
angle: 1~180, resolution: 0.01
¨¹ Surface
tension: 0.1~2000 mN/m, resolution: 0.01
(a) Cluster computational server
(b) GPU workstations
High-performance
Computers
